Unit：mm

http://www.ddknet.co.jp

CM03 Series

2

◎ Specifications and/or dimensions in this catalog are subject to change without notice. ◎ Your checking the latest specifications with our drawings would be highly appreciated.

P/N : CM03-J-PC

P/N : CM03-P-SC

Plug

(With Socket Contacts)

Jack

(With Pin Contacts)

・4 pieces or 5 pieces of unassembled socket contacts to be supplied together with connectors

・Crimp termination type.

・4 pieces or 5 pieces of unassembled socket contacts to be supplied together with connectors

・Crimp termination type.

Item

P/N

    A Set of Crimp Tool

 357J-22483

 Contents

Hand Tool

 357J-12610

Locator

357J-22484

Inspection Gauge for AWG18

357J-22276-1

Inspection Gauge for AWG14

357J-22276-2

・A crimp tool should is be needed for plugs and jacks.

Pin Contacts

Socket Contacts

４

２

３

１

（75）

24

7

8-16UN-2A

２

５

３

４

１

7

24

（75）

8-16UN-2A

２

１

３

４

7

24

8-16UN-2A

(78)

３

２

１

４

５

7

(78)

24

8-16UN-2A

28.5

26.45

P/N : CM03-P4S

P/N : CM03-P5S

P/N : CM03-J5P

P/N : CM03-J4P

(4 positions for power)

(4 positions for power)

(5 positions for signal)

(5 positions for signal)

(Flat surfaces for

spanner wrench)

(Flat surfaces for

spanner wrench)

(Flat surfaces for

spanner wrench)

(Flat surfaces for

spanner wrench)

◆ CONFIGURATION OF CRIMP CONTACTS

◆ CRIMP TOOL
