Version 1.0
LT PWSG
2016-03-18
13
Note:
The upper solder pad layout represents the
recommended solder pad for top mounting.
For superior solder joint connectivity results we
recommend soldering under standard nitrogen
atmosphere.
Package not suitable for ultra sonic cleaning.
Anm.:
Das obere Lötpaddesign zeigt das empfohlene
Lötpad für die Montage von oben.
Um eine verbesserte Lötstellenkontaktierung zu
erreichen, empfehlen wir, unter Standard-
Stickstoffatmosphäre zu löten.
Das Gehäuse ist für Ultraschallreinigung nicht
geeignet.
