Document Number: 002-05615 Rev. *D

Page

64 of 112

MB9B410R Series

Parameter

Symbol

name

Conditions

Value

Unit

Remarks

Typ*2

Max*2

Timer

mode

current

ICCT

VCC

Main

Timer

mode

TA = + 25°C,

When LVD is off

3.2

*1, *3

TA = + 85°C,

When LVD is off

*1, *3

Sub

Timer

mode

TA = + 25°C,

When LVD is off

0.9

*1, *4

TA = + 85°C,

When LVD is off

*1, *4

Stop

mode

current

ICCH

Stop mode

TA = + 25°C,

When LVD is off

0.8

TA = + 85°C,

When LVD is off

*1: When all ports are fixed.

*2: VCC=5.5 V

*3: When using the crystal oscillator of 4 MHz(Including the current consumption of the oscillation circuit)

*4: When using the crystal oscillator of 32 kHz(Including the current consumption of the oscillation circuit)

Low-Voltage Detection Current

(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)

Parameter

Symbol

name

Conditions

Value

Unit

Remarks

Typ

Max

Low voltage

detection circuit

(LVD) power

supply current

ICCLVD

VCC

At operation

for interrupt

VCC = 5.5 V

μA

At not detect

Flash Memory Current

(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)

Parameter

Symbol

name

Conditions

Value

Unit

Remarks

Typ

Max

Flash memory

write/erase

current

ICCFLASH

VCC

MainFlash

At Write/Erase

11.4

13.1

WorkFlash

At Write/Erase

11.4

13.1

*: The current at which to write or erase Flash memory, ICCFLASH is added to ICC.

A/D Converter Current

(VCC = AVCC = 2.7V to 5.5V, VSS = AVSS = AVRL = 0V, TA = - 40°C to + 85°C)

Parameter

Symbol

name

Conditions

Value

Unit

Remarks

Typ

Max

Power supply

current

ICCAD

AVCC

At 1unit

operation

0.47

0.62

At stop

0.06

μA

Reference power

supply current

ICCAVRH

AVRH

At 1unit

operation

AVRH=5.5 V

1.1

1.96

At stop

0.06

μA
