SERIAL INTERFACE

Access to the configuration registers, general-purpose

memory and command and status registers is carried

out over an industry standard 2-wire serial interface

2C). SDA is a bi-directional data line and SCL is a

clock input. Data is clocked in on the rising edge of

SCL and clocked out on the falling edge of SCL. All

data transfers begin with the MSB.

During data

transfers SDA must remain stable while SCL is high.

Data is transferred in 8-bit packets with an intervening

clock period in which an Acknowledge is provided by

the device receiving data. The SCL high period (tHIGH)

is used for generating Start and Stop conditions that

precede and end most transactions on the serial bus.

A high-to-low transition of SDA while SCL is high is

considered a Start condition, while a low-to-high

transition of SDA while SCL is high is considered a

Stop condition.

The interface protocol allows operation of multiple

devices and types of devices on a single bus through

unique device addressing.

The address byte is

comprised of a 4-bit device type identifier (slave

address) and a 3-bit bus address. The remaining bit

indicates either a read or a write operation. Refer to

Table 1 for a description of the address bytes used by

the SMM205.

The device type identifier for the memory array, the

configuration registers and the command and status

registers are accessible with the same slave address.

It can be programmed to any four bit number 0000BIN

through 1111BIN.

The bus address bits, A2, A1 and A0, are hard wired

though pins 2, 4 and 6 (A2, A1 and A0). The bus

address accessed in the address byte of the serial

data stream must match the setting on the SMM205

address pins.

WRITE

Writing to the memory or a configuration register is

illustrated in Figures 9, 10, 11, 13, 14 and 16. A Start

condition followed by the address byte is provided by

the host; the SMM205 responds with an Acknowledge;

the host then responds by sending the memory

address pointer or configuration register address

pointer; the SMM205 responds with an acknowledge;

the host then clocks in one byte of data. For memory

and configuration register writes, up to 15 additional

bytes of data can be clocked in by the host to write to

consecutive addresses within the same page. After

the last byte is clocked in and the host receives an

Acknowledge, a Stop condition must be issued to

initiate the nonvolatile write operation.

READ

The address pointer for the configuration registers,

memory, command and status registers and ADC

registers must be set before data can be read from the

SMM205. This is accomplished by issuing a dummy

write command, which is simply a write command that

is not followed by a Stop condition. The dummy write

command sets the address from which data is read.

After the dummy write command is issued, a Start

command followed by the address byte is sent from

the host. The host then waits for an Acknowledge and

then begins clocking data out of the slave device. The

first byte read is data from the address pointer set

during the dummy write command. Additional bytes

can be clocked out of consecutive addresses with the

host providing an Acknowledge after each byte. After

the data is read from the desired registers, the read

operation is terminated by the host holding SDA high

during the Acknowledge clock cycle and then issuing a

Stop condition. Refer to Figures 12, 15 and 17 for an

illustration of the read sequence.

WRITE PROTECTION

The SMM205 powers up into a write protected mode.

Writing a code to the volatile write protection register

(write only) can disable the write protection. The write

protection register is located at address 42HEX. Writing

to the write protection register is shown in Figure 9.

Writing 0101BIN to bits [7:4] of the write protection

while writing 0101BIN to bits [3:0] allows writes to the

configuration registers. The write protection can be re-

enabled by writing other codes (not 0101BIN) to the

write protection register.

I2C PROGRAMMING INFORMATION
