UL23EB

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 8

www.unisonic.com.tw

QW-R125-071.c



ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

OUT Pin Voltage

-0.5 ~ 500

V

OUT Pin Current

5 ~ 60

mA

-0.5 ~ 500

V

REXT Pin Voltage

-0.5 ~ 8

V

-0.5 ~ 8

V

-0.5 ~ 8

V

Working temperature

-40 ~ +150

°C

Storage temperature

-50 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Power of IC Pin Voltage

6.8

V

OUT Pin Voltage

2.5

V

OUT Pin Withstanding Voltage

500

V

Output Current

5

60

mA

Quiescent Current

0.16

0.25

mA

REXT Pin Voltage

0.6/0.3

V

Output Current Accuracy

± 4

%

Temperature Compensate Point

130

°C
