35 / 37 page  Data Sheet ADAR2004 Rev. 0 | Page 35 of 37 Address Name Bits Bit Name Description Reset Access 0x079 MULT_EN_MODE_9 7 BPF_MD9 Multiplier Mode 9 BPF Select 0x0 R/W 6 LOAMP_EN_MD9 Multiplier Mode 9 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD9 Multiplier Mode 9 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD9 Multiplier Mode 9 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD9 Multiplier Mode 9 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD9 Multiplier Mode 9 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD9 Multiplier Mode 9 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD9 Multiplier Mode 9 High Band Active Enable 0x0 R/W 0x07A MULT_EN_MODE_10 7 BPF_MD10 Multiplier Mode 10 BPF Select 0x0 R/W 6 LOAMP_EN_MD10 Multiplier Mode 10 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD10 Multiplier Mode 10 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD10 Multiplier Mode 10 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD10 Multiplier Mode 10 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD10 Multiplier Mode 10 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD10 Multiplier Mode 10 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD10 Multiplier Mode 10 High Band Active Enable 0x0 R/W 0x07B MULT_EN_MODE_11 7 BPF_MD11 Multiplier Mode 11 BPF Select 0x0 R/W 6 LOAMP_EN_MD11 Multiplier Mode 11 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD11 Multiplier Mode 11 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD11 Multiplier Mode 11 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD11 Multiplier Mode 11 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD11 Multiplier Mode 11 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD11 Multiplier Mode 11 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD11 Multiplier Mode 11 High Band Active Enable 0x0 R/W 0x07C MULT_EN_MODE_12 7 BPF_MD12 Multiplier Mode 12 BPF Select 0x0 R/W 6 LOAMP_EN_MD12 Multiplier Mode 12 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD12 Multiplier Mode 12 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD12 Multiplier Mode 12 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD12 Multiplier Mode 12 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD12 Multiplier Mode 12 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD12 Multiplier Mode 12 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD12 Multiplier Mode 12 High Band Active Enable 0x0 R/W 0x07D MULT_EN_MODE_13 7 BPF_MD13 Multiplier Mode 13 BPF Select 0x0 R/W 6 LOAMP_EN_MD13 Multiplier Mode 13 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD13 Multiplier Mode 13 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD13 Multiplier Mode 13 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD13 Multiplier Mode 13 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD13 Multiplier Mode 13 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD13 Multiplier Mode 13 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD13 Multiplier Mode 13 High Band Active Enable 0x0 R/W 0x07E MULT_EN_MODE_14 7 BPF_MD14 Multiplier Mode 14 BPF Select 0x0 R/W 6 LOAMP_EN_MD14 Multiplier Mode 14 LO Amplifier Enable 0x0 R/W 5 MULT_LOW_RDY_MD14 Multiplier Mode 14 Low Band Ready Enable 0x0 R/W 4 MULT_LOW_ACT_MD14 Multiplier Mode 14 Low Band Active Enable 0x0 R/W 3 MULT_MID_RDY_MD14 Multiplier Mode 14 Mid Band Ready Enable 0x0 R/W 2 MULT_MID_ACT_MD14 Multiplier Mode 14 Mid Band Active Enable 0x0 R/W 1 MULT_HIGH_RDY_MD14 Multiplier Mode 14 High Band Ready Enable 0x0 R/W 0 MULT_HIGH_ACT_MD14 Multiplier Mode 14 High Band Active Enable 0x0 R/W |
|
