background image
Data Sheet
ADAR2004
Rev. 0 | Page 9 of 37
Pin No.
Mnemonic
Description
32
VPOS3
1.8 V Power Supply for the Digital Section. Connect this supply directly to VREG. Place a 1 µF
capacitor to ground as close as possible to VPOS3.
33
VREG
1.8 V Low Dropout (LDO) Output. Connect VREG directly to VPOS3.
35
LOIN
LO Input. LOIN is a single-ended, 50 Ω input operating from 2.4 GHz to 10.1 GHz, ac-coupled
internally. The nominal input power level is −20 dBm.
EPAD
Exposed Pad. The exposed pad must be connected to a ground plane with low thermal and
electrical impedance.
