Data Sheet

ADF5709

Rev. A | Page 3 of 9

SPECIFICATIONS

TA = −40°C to +85°C and VCC = 5 V, unless otherwise noted.

Table 1.

Parameter

Min

Typ

Max

Unit

Test Conditions/Comments

FREQUENCY

fOUT

9.85

20.5

GHz

Drift Rate

0.5

MHz/°C

Pulling

MHz p-p

Pulling into a 2.0:1 voltage standing wave ratio (VSWR)

Pushing

−240

MHz/V

Frequency = 20.5 GHz

OUTPUT POWER (POUT)

RFOUT

−4.5

dBm

Temperature = 25°C

−6

dBm

Supply Current (ICC)

HARMONICS, SUBHARMONICS

Second

−15

dBc

Third

−30

dBc

Measured to 16.67 GHz due to test equipment limitation

TUNING

Voltage (VTUNE)

−0.5

+23

Sensitivity

220

870

MHz/V

9.8 GHz to 20.5 GHz only

Tune Port Leakage Current

100

μA

VTUNE = 23 V

OUTPUT RETURN LOSS

SINGLE SIDEBAND PHASE NOISE

10 kHz Offset

−51

100 kHz Offset

−83

−70

dBc/Hz

1 MHz Offset

−115

10 MHz Offset

−135

dBc/Hz
