3 / 15 page

Data Sheet

ADRF5250

Rev. 0 | Page 3 of 15

SPECIFICATIONS

VDD = 5 V, VSS = 0 V, V1 = V2 = V3 = 0 V/VDD, TCASE = 25°C, 50 Ω system, unless otherwise noted.

Table 1.

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

FREQUENCY RANGE

0.1

GHz

INSERTION LOSS

Between RFC and RFx (On)

0.1 GHz to 2 GHz

1.3

2 GHz to 4 GHz

1.5

4 GHz to 6 GHz

1.8

ISOLATION

Between RFC and RFx (Off)

0.1 GHz to 2 GHz

2 GHz to 4 GHz

4 GHz to 6 GHz

RETURN LOSS

RFC and RFx (On)

0.1 GHz to 2 GHz

2 GHz to 4 GHz

4 GHz to 6 GHz

RFx (Off)

0.1 GHz to 2 GHz

2 GHz to 4 GHz

4 GHz to 6 GHz

SWITCHING

Rise Time

tRISE

10% to 90% of radio frequency (RF) output

Fall Time

tFALL

10% to 90% of RF output

On and Off Time

tON, tOFF

50% of digital control voltage (V1, V2, V3) to 90% of

RF output

150

Settling Time (RFx to RFx)

0.1 dB

50% of V1, V2, V3 to 0.1 dB of final RF output

400

0.05 dB

50% of V1, V2, V3 to 0.05 dB of final RF output

500

INPUT LINEARITY

0.1 dB Compression

P0.1dB

Third-Order Intercept

IP3

dBm

SUPPLY CURRENT

VDD, VSS pins

Positive

IDD

NVG enabled (VSS = 0 V)

360

µA

NVG disabled (VSS = −3.3 V)

280

µA

Negative

ISS

NVG disabled (VSS = −3.3 V)

−60

µA

DIGITAL CONTROL INPUTS

V1, V2, V3 pins

Voltage

Low

VINL

VDD = 3.3 V

0.8

VDD = 5 V

1.2

High

VINH

VDD = 3.3 V

1.3

3.3

VDD = 5 V

1.6

Current

Low and High

IINL, IINH

VDD = 3.3 V to 5 V

µA
