MSM586 Scheda tecnica(PDF) 3 Page - OKI electronic componets

Il numero della parte MSM586
Spiegazioni elettronici  Built-in 16 bit PWM and 8 bit A/D Converter, High-speed High-preformance 16 bit Microcontroller
PDF  24 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Produttore elettronici  OKI [OKI electronic componets]
Homepage  http://www.oki.com
Logo OKI - OKI electronic componets

MSM586 Scheda tecnica(HTML) 3 Page - OKI electronic componets

  MSM586 Datasheet HTML 1Page - OKI electronic componets MSM586 Datasheet HTML 2Page - OKI electronic componets MSM586 Datasheet HTML 3Page - OKI electronic componets MSM586 Datasheet HTML 4Page - OKI electronic componets MSM586 Datasheet HTML 5Page - OKI electronic componets MSM586 Datasheet HTML 6Page - OKI electronic componets MSM586 Datasheet HTML 7Page - OKI electronic componets MSM586 Datasheet HTML 8Page - OKI electronic componets MSM586 Datasheet HTML 9Page - OKI electronic componets Next Button
Zoom Inzoom in Zoom Outzoom out
 3 / 24 page
background image
SSP
LRB
PSW
PC
ALU
ALU Control
ACC
System Control
Instruction
Decoder
ROM
64 KB
Memory Control
Pointing R
Local R.
RAM
2 KB
EA
ALE/P5_5
PSEN/P5_4
RD/P7_1
WR/P7_0
WAIT/P7_2
AD0/P0_0
AD7/P0_7
A8/P1_0
A15/P1_7
A16/P9_0
A19/P9_3
Control
Registers
CPU Core
16-bit RTO/PWM
Timer
Serial Port
PWM
A to D
Converter
Event Timer
Interrupt
Peripheral
Port Control
*1
DSR TSR CSR
*2
P2_4/RT08
P2_5/RTO9
P6_2/RXD1
P6_3/TXD1
P6_4/RXC1
P6_5/TXC1
P7_4/PWM0
VREF
AGND
AI0
AI3
P4_0/ETMCK
P6_0/INTO
P6_1/INT1
P12_2/INT2
P12_3/INT3
NMI
P7_3/CLKOUT
