background image
2018 - 2020 Microchip Technology Inc.
DS00003561A-page 21
USB7252P
Note 3-1
The default function is not used in the USB7252P.
PF30
MSTR_I2C_CLK
MSTR_I2C_CLK
MSTR_I2C_CLK
MSTR_I2C_CLK
PF31
MSTR_I2C_DATA
MSTR_I2C_DATA
MSTR_I2C_DATA
MSTR_I2C_DATA
Note:
The default
PFx pin functions can be overridden with additional configuration by modification of the pin mux
registers. These changes can be made during the SMBus configuration stage, by programming to OTP
memory, or during runtime (after hub has attached and enumerated) by register writes via the SMBus slave
interface or USB commands to the internal Hub Feature Controller Device.
TABLE 3-5:
PF[31:2] FUNCTION ASSIGNMENT (CONTINUED)
Pin
Configuration 1
(SMBus/I2C)
Configuration 2
(I2S)
Configuration 3
(UART)
Configuration 4
(GPIO & FlexConnect)
