Data Sheet

ADPA7008

TABLE OF CONTENTS

analog.com

Rev. 0 | 2 of 28

Features................................................................ 1

Applications........................................................... 1

General Description...............................................1

Functional Block Diagram......................................1

Specifications........................................................ 3

20 GHz to 22 GHz Frequency Range................ 3

22 GHz to 40 GHz Frequency Range................ 3

40 GHz to 50 GHz Frequency Range ............... 4

50 GHz to 54 GHz Frequency Range ............... 4

Absolute Maximum Ratings...................................5

Thermal Resistance........................................... 5

Electrostatic Discharge (ESD) Ratings ..............5

ESD Caution.......................................................5

Pin Configuration and Function Descriptions........ 6

Interface Schematics..........................................6

Typical Performance Characteristics..................... 7

Lower Bias Operation.......................................15

Theory of Operation.............................................18

Applications Information...................................... 19

Typical Application Circuits ..............................19

Biasing the ADPA7008 with the Low Noise

LTM8063............................................................21

Biasing ADPA7008 with the HMC980LP4E.........24

Application Circuit Setup.................................. 24

Limiting VGATE for the ADPA7008 VGGx

Absolute Maximum Rating Requirement........24

HMC980LP4E Bias Sequence......................... 25

Constant Drain Current Biasing vs.

Constant Gate Voltage Biasing...................... 26

Constant IDD Operation.................................... 26

Outline Dimensions............................................. 28

Ordering Guide.................................................28

Evaluation Boards............................................ 28

REVISION HISTORY

7/2021—Revision 0: Initial Version
