background image
CC400
SWRS050
Page 29 of 32
32.
Plastic Tube Specification
SSOP 5.3mm (.208”) antistatic tube.
Tube Specification
Package
Tube Width
Tube Height
Tube
Length
Units per Tube
SSOP 28
10.6
4 mm
20”
47
Table 15: Plastic Tube Specification
33.
Carrier Tape and Reel Specification
Carrier tape and reel is in accordance with EIA Specification 481.
Tape and Reel Specification
Package
Tape Width
Component
Pitch
Hole
Pitch
Reel
Diameter
Units per Reel
SSOP 28
24 mm
12 mm
4 mm
13”
2000
Table 16: Carrier Tape and Reel Specification
34.
Ordering Information
Ordering part number
Description
CC400-STB2
CC400 8inch wafer, SSOP28 package, standard leaded assembly,
tubes with 47 pcs per tube
CC400-STR2
CC400 8inch wafer, SSOP28 package, standard leaded assembly, T&R
with 2000 pcs per reel
CC400-RTB2
CC400 8inch wafer, SSOP28 package, RoHS compliant Pb-free
assembly, tubes with 47 pcs per tube
CC400-RTR2
CC400 8inch wafer, SSOP28 package, RoHS compliant Pb-free
assembly, T&R with 2000 pcs per reel
CC400DK
CC400 Development Kit
CC400SK
CC400 Sample Kit ( 5 pcs.)
Table 17: Ordering Information
