background image
CC400
SWRS050
Page 12 of 32
Parameter
Symbol
Min
Max
Units
Conditions
CLOCK,
clock
frequency
FCLOCK
-
2
MHz
CLOCK low
pulse
duration
TCL,min
50
ns
The minimum time CLOCK can be low.
CLOCK high
pulse
duration
TCH,min
50
ns
The minimum time CLOCK can be high.
PDATA setup
time
TSD
5
-
ns
The minimum time data on PDATA must be ready
before the negative edge of CLOCK.
PDATA hold
time
THD
5
-
ns
The minimum time data must be held at PDATA,
after the negative edge of CLOCK.
CLOCK to
STROBE
time
TCS
5
-
ns
The minimum time after the negative edge of
CLOCK before positive edge of STROBE.
STROBE to
CLOCK time
TSC
5
-
ns
The minimum time after the negative edge of
STROBE before negative edge of CLOCK.
STROBE
pulse
duration
TS,min
50
ns
The minimum time STROBE can be high.
Rise time
Trise
100
ns
The maximum rise time for CLOCK and STROBE
Fall time
Tfall
100
ns
The maximum fall time for CLOCK and STROBE
Note: The set-up- and hold-times refer to 50% of VDD.
Table 10: Serial interface, timing specification.
