CASES

Angled corner

indicates pin one.

1

2

3

4

5

6

12

11

10

9

8

7

0.000

0.120 (3.05)

0.250 (6.35)

0.450 (11.43)

0.650 (16.51)

0.850 (21.59)

1.050 (26.67)

1.250 (31.75)

1.380 (35.05)

1.505 (38.23) max.

0.128 dia

(3.25).

0.040 dia

(1.02)

0.23 (5.8) Lead Length

TOP VIEW CASE U

MOR Series, MFL Series, MHP Series, MFLHP Series,

FMTR Series. SMFL Series, SMFLHP Series, SMHP Series,

FME EMI Filter, FMD270 EMI Filter, SFCS EMI Filter,

SFME EMI Filter, HUM70 Module, and LCM Module

Seam Seal

Seal hole: 0.100 ±0.002 (2.54 ±0.05)

Case U, Rev B, September 27, 2005

Please refer to the numerical dimensions for accuracy. All information is believed to be accurate,

but no responsibility is assumed for errors or omissions. Interpoint reserves the right to make

changes in products or specifications without notice.

Copyright © 1999-2005 Interpoint Corp. All rights reserved.

Case dimensions in inches (mm)

Tolerance ±0.005 (0.13) for three decimal places

±0.01 (0.3) for two decimal places

unless otherwise specified

CAUTION

Heat from reflow or wave soldering may damage the device.

Solder pins individually with heat application not exceeding 300°C for 10 seconds per pin

6
