REEL DIMENSIONS in millimeters

LEADER AND TRAILER DIMENSIONS in millimeters

COVER TAPE PEEL STRENGTH

According to DIN EN 60286-3

0.1 N to 1.3 N

300 mm/min. ± 10 mm/min.

165° to 180° peel angle

Drawing-No.: 9.800-5052.V3-4

Issue: 1; 17.12.02

Form of the leave open of the wheel is supplier specific.

Dimensions according to IEC EN 60 286-3

Tape width: 24

Technical drawing

according to DIN

specifications

Reel hub 2:1

Ø 20.2

min.

24.4

+3

-0

Trailer

Leader

no devices

min.

200

min. 400

Start

End

devices

96 11818

no devices
