TSOP531..DF1P, TSOP533..DF1P, TSOP535..DF1P

www.vishay.com

Vishay Semiconductors

Datasheet Values Refer to PCN-OPT-1225-2022-REV-0

Rev. 1.3, 17-Jan-2023

11

Document Number: 82891

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000

ORDERING INFORMATION

Note

• d = “digit”, please consult the list of available series on the previous page to create a valid part number

Example: TSOP53138DF1P

PACKAGING QUANTITY

• 1100 pieces per reel

• 1 reel per box

LABEL

Standard bar code labels for finished goods

The standard bar code labels are product labels and used

for identification of goods. The finished goods are packed in

final packing area. The standard packing units are labeled

with standard bar code labels before transported as finished

goods to warehouses. The labels are on each packing unit

and contain Vishay Semiconductor GmbH specific data.
