46 / 56 page  Reference Part number Description Value Manufacturer R3 0603 SMD resistor Not mounted (330 Ω) C1 0603 MLCC Not mounted (1 µF, 35 V) Ciso+, Ciso- 0805 MLCC Not mounted (1 µF, 50 V) Dz1 Zener diode Not mounted (Vz1 = 12 V) Dz2 4.7 V Zener diode Not mounted (Vz1 = 4.7 V) Q1 2STR1215 NPN power transistor Not mounted ST Figure 52. STEVAL-L6983IV1 (top layer) Figure 53. STEVAL-L6983IV1 (bottom layer) L6983I Application board DS14040 - Rev 1 page 46/56 |
|
