Safety CPU unit

Safety I/O unit

Safety Monitor

The NA Series can directly access safety CPU units and safety

I/O units, which was previously impossible. There is no need to

create any special screen to monitor their device variables and

I/O settings.

The I/O Matrix Monitor displays device variables and external

exposed variables used in safety programs, allowing you to see

outputs (error state) and corresponding inputs (causal condition).

The Safety Input/Output Unit Monitor shows the ON/OFF status of safety I/O

units and information on components connected to individual I/O terminals,

enabling efficient monitoring of the entire system including safety components.

Keep Machine Running

- Minimize downtime

If something unexpected happens in your machine, it is crucial to identify the cause and solve the problem quickly.

As part of the Sysmac automation platform, the NA Series helps minimize machine downtime.

Troubleshooter

The Troubleshooter on the NA Series allows you to

directly monitor and release the NJ/NX/NY Controller

errors and events as well as the user-defined errors

and events. There is no need for support software

running on a PC.

Error occurs

NJ/NX/NY troubleshooter

Error details can be checked.

N E W

6

Bringing technology to life - NA Series, Machine Interface
