Usability: Debugging

- Easy and fast debugging in integrated

development environment

Operations, such

as stop and step

execution, can be

performed for both

HMI and controller

simulations.

Integrated Simulator

The NJ/NX/NY Controller Simulator and

NA HMI Simulator can be displayed

on one screen. You can quickly debug

the controller program and the HMI

application at the same time.

Switchable to the screen for desining.

•

You can display the selected page and change properties without stopping the

Simulator. Immediate debugging during simulation before building will prevent

you from forgetting to correct errors and reduce the frequency of building.

Errors found during

simulation can be

corrected immediately.

Pages and languages can

be changed anytime.

Change to TRUE

Check the alarm

with the Simulator

Watch Tab Page

The same GUI as the NJ/NX/NY Controller is used. Register the variable to monitor/change and then change its

value on the Watch Tab Page to easily debug screens with the NA Simulator without the physical HMI.
