AM26LS32AC, AM26LS32AI, AM26LS32AM

AM26LS33AC, AM26LS33AM

SLLS115F – OCTOBER 1980 – REVISED SEPTEMBER 2016

www.ti.com

Product Folder Links: AM26LS32AC AM26LS32AM AM26LS33AM

Submit Documentation Feedback

(1)

All typical values are at VCC = 5 V, TA = 25°C, and VIC = 0.

6.6 Switching Characteristics

CL = 15 pF, VCC = 5 V, and TA = 25°C (see Parameter Measurement Information; unless otherwise noted)

PARAMETER

MIN

TYP(1)

MAX

UNIT

tPLH

Propagation delay time, low-to-high-level output

tPHL

Propagation delay time, high-to-low-level output

tPZH

Output enable time to high level

tPZL

Output enable time to low level

tPHZ

Output disable time from high level

tPLZ

Output disable time from low level

6.7 Dissipation Ratings

PACKAGE

TA ≤ 25°C

POWER RATING

DERATION FACTOR

ABOVE TA = 25°C

TA = 70°C

POWER RATING

TA = 125°C

POWER RATING

1375 mW

11 mW/°C

880 mW

275 mW

1375 mW

11 mW/°C

880 mW

275 mW
