background image
40
4173D–USB–02/06
AT89C5132
Table 10-1.
IPH0 Register
IPH0 (S:B7h) – Interrupt Priority High Register 0
Reset Value = X000 0000b
765
4321
0
-
IPHAUD
–
IPHS
IPHT1
IPHX1
IPHT0
IPHX0
Bit Number
Bit
Mnemonic
Description
7-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
6
IPHAUD
Audio Interface Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
5IPHMP3
MP3 Decoder Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
4IPHS
Serial Port Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
3IPHT1
Timer 1 Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
2IPHX1
External Interrupt 1 Priority Level MSB
Refer to Table 33 for priority level description.
1-
Reserved
The value read from this bit is indeterminate. Do not set this bit.
0IPHX0
External Interrupt 0 Priority Level MSB
Refer to Table 33 for priority level description.
