41
4173D–USB–02/06
AT89C5132
Table 37. IPH1 Register
IPH1 (S:B3h) – Interrupt Priority High Register 1
Reset Value = 0000 0000b
765
4321
0
-
IPHUSB
–
IPHKB
IPHADC
IPHSPI
IPHI2C
IPHMMC
Bit Number
Bit
Mnemonic
Description
7-
Reserved
The value read from this bit is always 0. Do not set this bit.
6
IPHUSB
USB Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
5-
Reserved
The value read from this bit is always 0. Do not set this bit.
4
IPHKB
Keyboard Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
3
IPHADC
A to D Converter Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
2IPHSPI
SPI Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
1IPHI2C
Two Wire Controller Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
0
IPHMMC
MMC Interrupt Priority Level MSB
Refer to Table 33 for priority level description.
