Position Sensor IC with Speed and Direction Output

A1696PKH

13

Allegro MicroSystems

955 Perimeter Road

Manchester, NH 03103-3353 U.S.A.

www.allegromicro.com

Package KH, 3-Pin SIP

For Reference Only – Not for Tooling Use

(Reference DWG-9073)

Dimensions in millimeters – NOT TO SCALE

Dimensions exclusive of moldflash, gate burrs, and dambar protrusions

Exact case and lead configuration at supplier discretion within limits shown

0.90 ±0.05

2

3

1

B

4 × 20°

4 × 10°

A

D

Branded

Face

2 × 2.40 ±0.10

5.40 ±0.10

2.95

1.25

8.47 REF

0.79 REF

7.00 ±0.10

18.19 ±0.05

25.60 ±0.10

1.60 ±0.10

1.60 ±0.10

A

B

C

C

D Branding scale and appearance at supplier discretion

7.00 ±0.10

E

F

F

F

F

F

F

E

12 × 0.30 REF

3 × 1.00 ±0.10

3 × 0.51 ±0.10

2 × 1.27 ±0.10

0.25±0.05 REF

2.00 ±0.10

0.30 REF

Mold Ejector

Pin Indent

8.25 REF

Standard Branding Reference View

Dambar removal protrusion (12×)

Gate and tie bar burr area

Active Area Depth 0.42 REF

Molded Lead Bar to prevent damage to leads during shipment

Hall elements (F1, F2, F3); not to scale

F3

F2

F1

2.25

F

1.25

F

2.25

XXX

Date Code

Lot Number

Line 1, 2, 3, 4: Max. 10 characters per line

Line 1: Logo A

Line 2: 7-digit alpha numeric Lot Number

Line 3: Last 3 digits of Part Number;

Additional suffixes may be added

to Part Number as required

Line 4: 4-digit Date Code
