Data Sheet
AD8000
Rev. C | Page 7 of 17
FREQUENCY (MHz)
–7
–6
–5
–4
–3
–2
–1
0
1
2
3
0.1
1
10
100
1000
RL = 1k
G = +1
RF = 432
VOUT = 200mV p-p
LFCSP
VS = +5V, RS = 0
VS = 5V, RS = 50
VS = +5V, RS = 50
VS = 5V, RS = 0
Figure 11. Small Signal Frequency Response vs. Supply Voltage
–9
–6
–3
0
3
6
9
FREQUENCY (MHz)
10
1
100
1000
RL = 150
G = +1
RF = 432
VOUT = 200mV p-p
LFCSP
VS = 5V
VS = +5V
Figure 12. Small Signal Frequency Response vs. Supply Voltage
5.5
5.6
5.7
5.8
5.9
6.0
6.1
6.2
6.3
6.4
6.5
FREQUENCY (MHz)
1
100
10
VS = 5V
RL = 150
VOUT = 2V p-p
G = +2
RF = 432
SOIC
LFCSP
Figure 13. 0.1 dB Flatness
–3
0
3
6
9
FREQUENCY (MHz)
10
1
100
1000
VS = 5V
G = +2
RL = 150
VOUT = 200mV p-p
LFCSP
–40
C
+125
C
+25
C
Figure 14. Small Signal Frequency Response vs. Temperature
–3
0
3
6
9
FREQUENCY (MHz)
10
1
100
1000
VS = 5V
G = +2
RL = 1k
VOUT = 200mV p-p
LFCSP
–40
C
+125
C
+25
C
Figure 15. Small Signal Frequency Response vs. Temperature
–3
0
3
6
9
FREQUENCY (MHz)
10
1
100
1000
VS = 5V
G = +2
RL = 150
VOUT = 2V p-p
LFCSP
+125
C
+25
C
–40
C
Figure 16. Large Signal Frequency Response vs. Temperature
