5 / 11 page

Test

Parameter

Symbol

Color

Min.

Typ.

Max.

Units

Conditions

Peak Wavelength

λPEAK

Red

660

IF = 20 mA

Green

568

Blue

430

Dominant Wavelength

λd

Red

643

IF = 20 mA

Green

573

Blue

466

Spectral Line Half Width

λd

Red

IF = 20 mA

Green

Blue

Forward Voltage

Red

1.8

2.0

IF = 20 mA

Green

2.2

2.6

Blue

3.8

4.5

Reverse Current[1]

Red

100

µAVR = 5 V

Green

100

Blue

100

Note:

1. Typical specification for reference only. Do not exceed absolute maximum ratings.

Parameter

Symbol

Red

Green

Blue

Units

Power Dissipation per Dot

Peak Forward Current per Dot[1,2]

IPEAK

100

Average Forward Current per Dot

IF AVG

15[3]

15[4]

20[5]

Reverse Voltage per Dot

555V

Operating Temperature

–35 to 80

°C

Storage Temperature

–40 to 80

°C

Soldering Conditions

Temperature

260

°C

(2 mm [0.079 in.] Below Seating Plane)

Time

Notes:

1. Do not exceed maximum average current per dot.

2. Maximum peak forward current stated at 1/8 duty factor, 10 kHz.

3. Derate above 25

°C at 0.20 mA/°C for red color.

4. Derate above 25

°C at 0.17 mA/°C for green color.

5. Derate above 25

°C at 0.33 mA/°C for blue color.

Optical/Electrical Characteristics at TA=25°C

Absolute Maximum Ratings at TA=25

°C
