10 / 11 page

Contrast Enhancement

For information on contrast

enhancement, please see

Application Note 1015.

Soldering/Cleaning

Cleaning agents from the ketone

family (acetone, methyl ethyl

ketone, etc.) and from the

chlorinated hydrocarbon family

(methylene chloride, trichloro-

ethylene, carbon tetrachloride,

etc.) are not recommended for

cleaning LED parts. All of these

Figure 11. Color Coordinate (NTSC vs. LED).

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

LED (RICH COLOR)

NTSC

LED

(FULL

COLOR)

GLED (InGaN GREEN) – 526 nm

GNTSC

GLED (GaP GREEN) – 573 nm

RNTSC

RLED (AlGaAs) – 643 nm

BLED (GaN BLUE) – 466 nm

BNTSC

various solvents attack or dissolve

the encapsulating epoxies used

to form the package of plastic

LED parts.

For information on soldering

LEDs please refer to Application

Note 1027.

Device Reliability

For reliability information, please

see the reliability data sheet

8 x 8 Rich Color General Purpose

Dot Matrix Displays.
