CC1010

SWRS047A

Page 45 of 146

which can then not be used for other

purposes. If in-circuit debugging is not

required, the RESERVED register shown

below may be used for any purpose.

Writing to it will have no effect on the

operation of

CC1010.

Great caution should be used when the

RADR

written.

Since

the

address

consists of two bytes (RADRL and RADRH),

there will be a short interval where the

address is not valid as only one of the

bytes

are written

at a

time.

this

intermediate address point to the very

same location as of the code modifying the

RADR, a malfunction will occur. One

possible work-around is to first write

RADRH to a value pointing to a memory

location not used by the code.

RESERVED (0xE7) - Reserved register, used by Chipcon debugger software

Bit

Name

R/W

Reset value

Description

7:0

RESERVED(7:0)

R/W

0x00

Reserved register, which is used by Chipcon

debugger software. RESERVED may be used for

other purposes if Chipcon’s debugger software is

not needed.

RDATA (0xB9) - Replacement Data

Bit

Name

R/W

Reset value

Description

7:0

RDATA(7:0)

R/W

0x00

Replacement data.

Used to replace the byte at program memory

address RADR with the data from RDATA, if

RADR

> 0.

RADRH (0xBB) - Replacement address, high byte

Bit

Name

R/W

Reset value

Description

7:0

RADR(15:8)

R/W

0x00

Replacement address, high byte.

Used to replace the byte at program memory

address RADR with the data from RDATA, if

RADR

> 0.

RADRL (0xBA) - Replacement address, low byte

Bit

Name

R/W

Reset value

Description

7:0

RADR(7:0)

R/W

0x00

Replacement address, low byte.

Used to replace the byte at program memory

address RADR with the data from RDATA, if

RADR

> 0

15.16 Chip Version / Revision

CC1010 has a SFR register CHVER that can

be read to decide the chip type and

current revision. The register description is

shown below.

CHVER (0x9F) - Chip Version / Revision Register

Bit

Name

R/W

Reset value

Description

7:2

CHIP_TYPE

0x00

CHIP_TYPE

is a read-only status word, which

gives the type number of the chip.

000000 :

CC1010

000001 - 111111 : Reserved for future use

1:0

CHIP_REV

0x01

CHIP_REV

is a read only status word, which gives

the chip revision number of the chip. Current chip

revision is 01
