115 / 150 page  CC1010 SWRS047A Page 115 of 146 TEST5 (0xFE) – PLL Test Register 5 Bit Name R/W Reset value Description 7:6 - R0 0x00 Reserved, read as 0 5 CHP_DISABLE R/W 0 PLL Charge Pump disable 0 : Charge Pump is enabled (normal function) 1 : Charge Pump is disabled 4 VCO_OVERRIDE R/W 0 VCO array override 0 : VCO array is not overridden (normal function) 1 : VCO array is set by VCO_AO(3:0) 3:0 VCO_AO(3:0) R/W 0x08 VCO Array override value TEST4 (0xFD) – PLL Test Register 4 Bit Name R/W Reset value Description 7:6 - R/W 0x00 Reserved, read as 0 5:0 L2KIO R/W 0x25 Constant charge pump current scaling / rounding factor. Sets bandwidth of PLL. Default value is 0x25 and shall be used for all modes TEST3 (0xFC) – PLL Test Register 3 Bit Name R/W Reset value Description 7:5 - R0 0x00 Reserved, read as 0 4 BREAK_LOOP R/W 0 Break frequency synthesis PLL 0 : PLL loop closed (normal operation) 1 : PLL loop open 3:0 CAL_DAC_OPEN (3:0) R/W 100 Calibration DAC override value, active when BREAK_LOOP is set TEST2 (0xFB) – PLL Test Register 2 Bit Name R/W Reset value Description 7:5 - R0 0x00 Reserved, read as 0 4:0 CHP_CURRENT (4:0) R None Status vector defining the applied charge pump current TEST1 (0xFA) – PLL Test Register 1 Bit Name R/W Reset value Description 7:4 - R0 0x00 Reserved, read as 0 3:0 CAL_DAC(3:0) R None Status vector defining the applied calibration DAC value TEST0 (0xF9) – PLL Test Register 0 Bit Name R/W Reset value Description 7:4 - R0 0x00 Reserved, read as 0 3:0 VCO_ARRAY(3:0) R 0x00 Status vector defining the applied VCO array |
|
