ADPA7005AEHZ-R7 datasheet(2/24 Pages) AD

2 / 24 page

Data Sheet

ADPA7005

TABLE OF CONTENTS

analog.com

Rev. A | 2 of 24

Features................................................................ 1

Applications........................................................... 1

General Description...............................................1

Functional Block Diagram......................................1

Specifications........................................................ 3

18 GHz to 20 GHz Frequency Range................ 3

20 GHz to 24 GHz Frequency Range................ 3

24 GHz to 34 GHz Frequency Range................ 4

34 GHz to 44 GHz Frequency Range ............... 4

Absolute Maximum Ratings...................................5

Thermal Resistance........................................... 5

Electrostatic Discharge (ESD) Ratings...............5

ESD Caution.......................................................5

Pin Configuration and Function Descriptions........ 6

Interface Schematics ............................................ 7

Typical Performance Characteristics..................... 8

Constant IDD Operation.................................... 15

Theory of Operation.............................................16

Applications Information...................................... 17

Biasing ADPA7005 with the HMC980LP4E.........19

Application Circuit Setup.................................. 19

Limiting VGATE and VNEG for ADPA7005

VGGx Absolute Maximum Rating

Requirement...................................................19

HMC980LP4E Bias Sequence......................... 22

Constant Drain Current Biasing vs.

Constant Gate Voltage Biasing...................... 23

Outline Dimensions............................................. 24

Ordering Guide.................................................24

Evaluation Boards............................................ 24

REVISION HISTORY

1/2022—Revision A: Initial Version

ADPA7005AEHZ-R7 Scheda tecnica(PDF) 2 Page - Analog Devices
