WINCS02IC and WINCS02 Family

Electrical Specifications

Data Sheet

DS70005577B - 31

Table 3-6. I/O Pin DC Electrical Specifications (continued)

DC Characteristics

Standard Operating Conditions: VDD = VDDIO = 3.0V to 3.6V (unless

otherwise stated)

Operating Temperature:

-40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ TA ≤ +105°C for V-temp

Param. No. Symbol

Characteristics

Min.

Typ.

(1)

Max.

Units Conditions

DI_13

IIL

Input pin leakage

current

-1

—

µA

—

Note:

1. This parameter is characterized but not tested in manufacturing.

3.1.4.2 WINCS02IC Wi-Fi® Current Consumption

Table 3-7. Wi-Fi® Current Consumption DC Electrical Specifications

DC Characteristics(1)(2)

Standard Operating Conditions: VDD=VDDIO= 3.0V to 3.6V

(unless otherwise stated)

Operating Temperature:

-40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ TA ≤ +105°C for V-temp

Param.

No.

Symbol Device States

Code Rate

Output

Power

(Typ.)

(dBm)

Current

(Typ.) (mA)

Max.

Units Conditions

IWF_TX

IDD

On_Transmit

802.11b 1 Mbps

288

—

VDD = VDDIO = 3.3V

802.11b 1 Mbps

263

—

802.11b 11 Mbps

289

—

802.11g 6 Mbps

287

—

802.11g 54 Mbps

263

—

802.11n MCS0

279

—

802.11n MCS7

262

—

802.11n MCS7

249

—

IWF_RX

IDD

On_Receive

802.11b 1 Mbps

—

802.11n MCS7

—

Notes:

1. Tested on channel 7 using an internal test firmware that provides manual control of the data rate. In the Application

mode firmware, the data rate is selected automatically based on the RSSI and other variables.

2. Data in the “Typ.” column is at 3.3V, 25°C unless otherwise stated.

3. These parameters are characterized but not tested in manufacturing.

3.1.4.3 Extreme Deep Sleep (XDS) Current Consumption

The WINCS02 Module supports Extreme Deep Sleep (XDS) mode, which can be enabled using the

appropriate API. For details, refer to MPLAB® Harmony WINCS02 WLAN Library. To exit XDS mode,

asset the MCLR pin and complete the full driver initialization.
