WINCS02IC and WINCS02 Family

Electrical Specifications

Data Sheet

DS70005577B - 36

Table 3-14. WINCS02IC Receiver Performance Characteristics(1) (continued)

RF Characteristics

Standard Operating Conditions:

VDD=VDDIO= 3.0V to 3.6V (unless

otherwise stated)

Operating Temperature:

-40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ TA ≤ +105°C for V-temp

Temp

Param. No. Characteristics

Description(5)

Min.

Typ

Max.

Units

Notes:

1. Measured after RF matching network (assume 50Ω impedance).

2. RF performance is ensured at 3.3V, 25°C, with a 2-3 dB change at boundary conditions.

3. The availability of some specific channels and/or operational frequency bands are country-dependent and must be pro-

grammed in the host product at the factory to match the intended destination. Regulatory bodies prohibit exposing the

settings to the end user. This requirement needs to be taken care of via host implementation.

4. The host product manufacturer must ensure that the RF behavior adheres to the certification (for example, FCC, ISED)

requirements when the module is installed in the final host product.

5. This parameter is characterized but not tested in manufacturing.

6. This parameter is characterized and tested in manufacturing.

3.1.6.2 WINCS02IC Transmitter Performance

Table 3-15. WINCS02IC Transmitter Performance Characteristics

RF Characteristics

Standard Operating Conditions: VDD=VDDIO= 3.0V to

3.6V (unless otherwise stated)

Operating Temperature:

-40°C ≤ TA ≤ +85°C for Industrial

-40°C ≤ TA ≤ +105°C for V-temp

Param.

No.

Characteristics

Description(8)

Min.

Typ(3)

Max.

Units

WF_TX_1 Frequency

—

2412

—

2472

MHz

WF_TX_2 Output power(1)(2) 802.11b

1 Mbps DSSS(9)

—

dBm

2 Mbps DSSS

—

5.5 Mbps CCK

—

11 Mbps CCK

—

WF_TX_3 Output power(1)(2) 802.11g

6 Mbps OFDM

—

dBm

9 Mbps OFDM

—

12 Mbps OFDM

—

18 Mbps OFDM

—

24 Mbps OFDM

—

36 Mbps OFDM

—

48 Mbps OFDM

—

17.5

—

54 Mbps OFDM(9)

—
