www.g eeh y.co m
Pag e 70
7. Packaging information
7.1.
Reel packaging
Figure 32 Specification Drawing of Reel Packaging
A0
Dimension designed to accommodate the component width
B0
Dimension designed to accommodate the component length
K0
Dimension designed to accommodate the component thickness
W
Overall width of the carrier tape
Quadrant Assignments for PIN1 Orientation in Tape
Reel Dimensions
