8

EJ1

Ratings

* Auxiliary output can be allocated using the bus output allocation for each Basic Unit.

Characteristics

Communications

*1. Port B communications for the End Unit cannot be used when port C communications for the HFU is used.

*2. Port A connector communications and port A terminal communications cannot be used at the same time.

End Unit/EJ1

C-EDU

Power supply voltage

24 VDC

Operating voltage range

85% to 110% of rated voltage

Auxiliary output

*

Outputs

2

Transistor outputs

Max. operating voltage: 30 VDC, Max. load current: 50 mA

Ambient temperature range

Operating:

−10°C to 55°C

Storage:

−25°C to 65°C (with no icing or condensation)

Ambient humidity range

Operating: 25% to 85% (with no condensation)

Insulation resistance

20 M

Ω min. (at 500 VDC)

Dielectric strength

600 VAC, 50/60 Hz for 1 min between current-carrying terminals of different polarity

Vibration resistance

10 to 55 Hz, 20 m/s2 for 2 hours each in X, Y, and Z directions

Shock resistance

150 m/s2, 3 times each in 6 directions

Weight

70 g

Degree of protection

End Unit case: IP20, Terminal section: IP00

Standards

Approved standards

UL61010C-1, CSA C22.2 No.1010-1

EMC Directive

Same as for the Basic Unit. Refer to page 3.

Port B

*1

Basic Unit Communications (Refer to “Communications Specifications” on page 4.)

Port A

Basic Unit Communications (Refer to “Communications Specifications” on page 4.)

Port A connector

*2

E58-CIFQ1
