TLV2211, TLV2211Y

Advanced LinCMOS

™ RAIL-TO-RAIL

MICROPOWER SINGLE OPERATIONAL AMPLIFIERS

SLOS156B – MAY 1996 – REVISED JANUARY 1997

18

POST OFFICE BOX 655303

TYPICAL CHARACTERISTICS

Figure 23

LARGE-SIGNAL DIFFERENTIAL

vs

FREE-AIR TEMPERATURE

TA – Free-Air Temperature – °C

– 50

– 25

0

25

50

75

100

RL = 10 kΩ

RL = 1 MΩ

10 3

10 2

10 1

1

VDD = 3 V

VIC = 1.5 V

VO = 0.5 V to 2.5 V

– 75

125

Figure 24

LARGE-SIGNAL DIFFERENTIAL

vs

FREE-AIR TEMPERATURE

TA – Free-Air Temperature – °C

104

103

102

101

1

– 75

– 50

– 25

0

25

50

75

100

125

VDD = 5 V

VIC = 2.5 V

VO = 1 V to 4 V

RL = 1 MΩ

RL = 10 kΩ

Figure 25

f– Frequency – Hz

vs

FREQUENCY

10 1

10 2

10 3

10 4

AV = 100

AV = 10

AV = 1

VDD = 3 V

TA = 25°C

10 3

10 2

101

1

Figure 26

f– Frequency – Hz

vs

FREQUENCY

AV = 100

AV = 1

VDD = 5 V

TA = 25°C

1

101

102

103

104

AV = 10

10 3

10 2

101

† Data at high and low temperatures are applicable only within the rated operating free-air temperature ranges of the various devices.

‡ For all curves where VDD = 5 V, all loads are referenced to 2.5 V. For all curves where VDD = 3 V, all loads are referenced to 1.5 V.
