AD8432ACPZ-R7 Scheda tecnica(PDF) 3 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
AD8432ACPZ-R7 Scheda tecnica(HTML) 3 Page - Analog Devices |
|
|
3 / 28 page  AD8432 Rev. 0 | Page 3 of 28 SPECIFICATIONS VS = 5 V, TA = 25°C, RS = RIN = 50 Ω, RFB =150 Ω, CSH = 47 pF, RSH = 15 Ω, RL = 500 Ω (per SE output), CL = 5 pF (per SE output), G = 12.04 dB (single-ended input to differential output), f = 1 MHz, unless otherwise specified. Table 1. Parameter Conditions Min Typ Max Unit DYNAMIC PERFORMANCE Gain Range Input to differential output (selectable gain) 12.04 24.08 dB Input to single output (selectable gain) 6.02 18.06 dB Gain Error 0.1 1 dB −3 dB Small Signal Bandwidth RIN unterminated, RFB = ∞, CSH = 0 pF, RSH = 0 Ω G = 12.04 dB 200 MHz G = 18.06 dB 90 MHz G = 21.58 dB 50 MHz G = 24.08 dB 32 MHz −3 dB Large Signal Bandwidth VOUT = 2 V p-p 42 MHz Slew Rate (Rising Edge) VOUT = 2 V p-p, f = 10 MHz 295 V/μs Slew Rate (Falling Edge) VOUT = 2 V p-p, f = 10 MHz 170 V/μs Overdrive Recovery Time 10 ns DISTORTION/NOISE PERFORMANCE Input Voltage Noise RFB = ∞ 0.85 nV/√Hz Input Current Noise RFB = ∞ 2.0 pA/√Hz Noise Figure Unterminated RS = 50 Ω, RFB = ∞ 2.8 dB Active Termination RS = RIN = 50 Ω, RFB = 150 Ω 4.8 dB RS = 50 Ω, RFB = 226 Ω, RIN = 75 Ω 4.2 dB RS = 50 Ω, RFB = 301 Ω, RIN = 100 Ω 3.2 dB RS = 50 Ω, RFB = 619 Ω, RIN = 200 Ω 2.1 dB RS = 50 Ω, RFB = 3.57 kΩ, RIN = 1 kΩ 2.3 dB Output Referred Noise G = 12.04 dB, RFB = ∞ 3.4 nV/√Hz G = 18.06 dB, RFB = ∞ 6.8 nV/√Hz G = 21.58 dB, RFB = ∞ 10.2 nV/√Hz G = 24.08 dB, RFB = ∞ 13.6 nV/√Hz Harmonic Distortion 1 MHz (VOUT = 1 V p-p) HD2 −67 dBc HD2, RS = 50 Ω, RIN unterminated −74 dBc HD3 −103 dBc HD3, RS = 50 Ω, RIN unterminated −106 dBc 1 MHz (VOUT = 2 V p-p) HD2 −65 dBc HD2, RS = 50 Ω, RIN unterminated −72 dBc HD3 −103 dBc HD3, RS = 50 Ω, RIN unterminated −92 dBc 10 MHz (VOUT = 1 V p-p) HD2 −66 dBc HD2, RS = 50 Ω, RIN unterminated −62 dBc HD3 −78 dBc HD3, RS = 50 Ω, RIN unterminated −73 dBc 10 MHz (VOUT = 2 V p-p) HD2 −60 dBc HD2, RS = 50 Ω, RIN unterminated −56 dBc HD3 −72 dBc HD3, RS = 50 Ω, RIN unterminated −65 dBc |
|
