SSM2377

Rev. 0 | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Absolute maximum ratings apply at 25°C, unless otherwise noted.

Table 2.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

VDD

Common-Mode Input Voltage

VDD

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

ESD Susceptibility

4 kV

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Junction-to-air thermal resistance (θJA) is specified for the worst-

case conditions, that is, a device soldered in a printed circuit

board (PCB) for surface-mount packages. θJA is determined

according to JEDEC JESD51-9 on a 4-layer PCB with natural

convection cooling.

Table 3. Thermal Resistance

Package Type

PCB

θJA

Unit

9-Ball, 1.2 mm × 1.2 mm WLCSP

2S2P

°C/W

ESD CAUTION

SSM2377ACBZ-R7 Scheda tecnica(PDF) 5 Page - Analog Devices
