U74LVC06A
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-438.B
SWITCHING CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Propagation delay from input
(nA) to output(nY)
tPLZ / tPZL
VCC=1.8±0.15V, RL=1KΩ
CL=30pF
1.4
3.9
ns
VCC=2.5±0.2V, RL=500Ω
1.0
3.1
ns
VCC=2.7V, RL=500Ω
CL=50pF
1.0
3.9
ns
VCC=3.3±0.3V, RL=500Ω
1.0
3.7
ns
OPERATING CHARACTERISTICS (TA=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Power Dissipation Capacitance
Per Inverter
CPD
VCC=1.8±0.15V
f=10MHZ
2.1
pF
VCC=2.5±0.2V
2.3
pF
VCC=3.3±0.3V
2.5
pF
