UNISONIC TECHNOLOGIES CO., LTD

U74LVC06A

CMOS IC

www.unisonic.com.tw

1 of 5

QW-R502-438.B

HEX INVERTER

BUFFERS/DRIVERS WITH

OPEN-DRAIN OUTPUTS

DESCRIPTION

The U74LVC06A contain six independent inverter buffers/drivers

with open drain outputs, and performs the Boolean function Y= A in

positive logic.

This device has power-down protective circuit preventing

destruction of the device when it is powered down.

FEATURES

* Operate From 1.65V to 3.6V

* Inputs and Open-Drain Outputs Accept Voltages to 5.5V

* IOFF Supports Partial-Power-Down Mode

* Low Power Dissipation

ORDERING INFORMATION

Ordering Number

Package

Packing

Lead Free

Halogen Free

U74LVC06AL-P14-R

U74LVC06AG-P14-R

TSSOP-14

Tape Reel

U74LVC06AL-P14-T

U74LVC06AG-P14-T

TSSOP-14

Tube
