Data Sheet

SSM2932

Rev. 0 | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

TA = 25°C, unless otherwise noted.

THERMAL RESISTANCE

θJA is specified for the worst-case conditions, that is, a device

soldered in a circuit board for surface-mount packages.

Table 3.

Parameter

Rating

Analog Supply Voltage (PVDD)

3.75 V

Input Voltage

1.8 VPEAK

Output ESD, Human Body Model

8 kV

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

−65°C to +165°C

Lead Temperature (Soldering, 60 sec)

300°C

Table 4. Thermal Resistance

Package Type

θJA

Unit

16-Ball, 1.64 mm × 1.64 mm WLCSP

°C/W

ESD CAUTION

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
