- 32 -

JANURARY 18, 2013 | DATA SHEET | Rev 3.5

IR3898

6A Highly Integrated SupIRBuck

Single-Input Voltage, Synchronous Buck Regulator

PD-97662

value may be obtained from the manufacturer’s

datasheets, design tools or SPICE models. Alternatively,

they may also be inferred from measuring the power

stage transfer function of the converter and measuring

the double pole frequency FLC and using equation (17)

to compute the small signal Co.

These result in:

FLC=25.2 kHz

FESR=5.3 MHz

Fs/2=300 kHz

Select crossover frequency F0=120 kHz

Since FLC<F0<Fs/2<FESR, Type III is selected to place the

pole and zeros.

Detailed calculation of compensation Type III:

Desired Phase Boost Θ = 70°

1 sin

21.2 kHz

1 sin







1 sin

680.6 kHz

1 sin







Select:

0.5*

10.6 kHz and





0.5*

300 kHz



Select C4 = 2.2nF.

Calculate R3, C3 and C2:

2 *

;

2.1 kΩ

osc





Select R3 = 2.0 kΩ:

;

7.5 nF, Select:

10 nF

2 *





;

265 pF, Select:

180 pF

2 *





Calculate R4, R5 and R6:

;

106 Ω, Select:

100 Ω

2 *





;

3.41 kΩ,

2 *





Select R5 = 3.32 kΩ:

;

2.37 kΩ Select:

2.37 kΩ

ref



Setting the Power Good Threshold

In this design IR3898 is used in normal (non-tracking,

non-sequencing) mode, therefore the PGood thresholds are

internally set at 90% and 120% of Vref. At startup as soon as

Vsns voltage reaches 0.9*0.5V=0.45V (Fig. 15), after 1.28ms

delay, PGood signal is asserted. As long as the Vsns voltage

is between the threshold range, Enable is high, and no fault

happens, the PGood remains high.

The following formula can be used to set the threshold.

VoutPGood_Th can be taken as 90% of Vout. Choose R7=3.32KΩ:

* 0.9 * 7

(34)

* 0.9

2.37

PGood Th

Vref

Vout

Vref







The PGood is an open drain output. Hence, it is necessary to

use a pull up resistor, RPG, from PGood pin to Vcc. The value

of the pull-up resistor must be chosen such as to limit the

current flowing into the PGood pin to less than 5mA when

the output voltage is not in regulation. A typical value used

is 49.9kΩ.

OVP comparator also uses Vsns signal for over Voltage

dectection.With above values for R7 and R8, OVP trip point

(Vout_OVP) is

*1.2*( 7

8) / 8 1.44

(35)

OVP

Vout

Vref







Vref Bypass Capacitor

A 100pF bypass capacitor is recommended to be placed

between Vref and Gnd pins.This capacitor should be placed as

close as possible to Vref pin.
