42 / 46 page

- 42 -

JANURARY 18, 2013 | DATA SHEET | Rev 3.5

IR3898

6A Highly Integrated SupIRBuck

Single-Input Voltage, Synchronous Buck Regulator

PD-97662

Figure 49b: IRDC3898 Demo board Layout Considerations – Bottom Layer

Analog Ground plane

Power Ground plane

Figure 49c: IRDC3898 Demo board Layout Considerations – Mid Layer 1

Figure 49d: IRDC3898 Demo board Layout Considerations – Mid Layer 2

Single point connection

between AGND & PGND,

should be close to the

SupIRBuck kept away from

noise sources

Feedback

and Vsns trace

routing should be kept away

from noise sources
