SAP5S / SAP51
Universal Actuator-Sensor Interface IC
Data Sheet
July 17, 2012
© 2012 Zentrum Mikroelektronik Dresden AG — Rev. 3.1
All rights reserved. The material contained herein may not be reproduced, adapted, merged, translated, stored, or used without
the prior written consent of the copyright owner. The information furnished in this publication is PRELIMINARY and subject to
changes without notice.
21 of 62
Master Request
Slave Response
Instruction
MNE
ST
CB
A4
A3
A2
A1
A0
I4
I3
I2
I1
I0
PB
EB
SB
I3
I2
I1
I0
PB
EB
Set ID Code
(RDIO)
01
A4
A3
A2
A1
A0
11000
PB
1
0011001
Set IO Config
(RDID)
01
A4
A3
A2
A1
A0
11001
PB
1
0011001
Set ID Code 2
(RID1)
01
A4
A3
A2
A1
A0
11010
PB
1
0011001
Set Control Code
(RID2)
01
A4
A3
A2
A1
A0
11011
PB
1
0011001
Set Control Code 2
(RES)
01
A4
A3
A2
A1
A0
10100
PB
1
0011001
Enter Program Mode
Safety
PRGM
01000001110111
--- no slave response ---
Table 7: SAP5 Additional Master Calls for Slave Configuration
