RM0345

CAN interface

Doc ID 024080 Rev 3

21/38

The cut trace options J6, J17, J18 and J19 has been put in the design of this board to select

the supply of the CAN transceiver between 5 V and 3.3 V. By this option is possible to

replace the ST L9616 High-Speed Transceiver mounted on board by default, with a different

transceiver that operates at 3.3 V.

Note:

Refer to Section Appendix D: Options placement for layout options placement.

Table 9.

J6, J17 and J7 FlexCAN interface selection

J6 (or J17 if 3.3V)

FlexCAN interface

closed

open

low speed operation (default)

(CAN baud rate up to 250kBaud)

open

closed

high speed operation

(CAN baud rate from 250kBaud to 1000kBaud)

Table 10.

CAN transceiver operating voltage selection

CAN Transceiver

J17

J18

J19

5V - ST L9616 High-Speed

Transceiver

Adjustable

Slope Control

open

3.3V - CAN transceiver

open

Adjustable

Slope Control

open
