2 / 13 page

NJG1507R

- 2 -

nABSOLUTE MAXIMUM RATINGS

(Ta=25°C, Zs=Zl=50

Ω)

PARAMETER

SYMBOL

RATINGS

UNITS

Input power

dBm

Control voltage

VCTR

6.0

Power dissipation

320

Operating Temp.

Topr

-30~+85

°C

Storage Temp.

Tstg

-40~+150

°C

nELECTRICAL CHARACTERISTICS

(VCTR (L)=0V, VCTR (H)=2.7V, Zs=Zo=50

Ω, T

a=25°C)

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Control voltage (L)

VCTR (L)

f=0.05~2.5GHz, Pin=22dBm

-0.2

0.2

Control voltage (H)

VCTR (H)

f=0.05~2.5GHz, Pin=22dBm

2.5

2.7

5.5

Control current

ICTR

f=0.05~2.5GHz, Pin=22dBm

5.0

8.0

Insertion loss1

LOSS1

f=1.0GHz, Pin=22dBm

0.4

0.7

Insertion loss2

LOSS2

f=2.0GHz, Pin=22dBm

0.5

0.8

Isolation 1

(PC-P1, PC-P2, P1-P2)

ISL1

f=1.0GHz, Pin=22dBm

Isolation 2

(PC-P1, PC-P2, P1-P2)

ISL2

f=2.0GHz, Pin=22dBm

Pin at 1dB

compression point 1

P-1dB (1)

f=2.0GHz

dBm

Pin at 1dB

compression point 2

P-1dB (2)

VCTR (H)=3.0V, f=2.0GHz

dBm

VSWR

f=0.05~2.5GHz, ON STATE

1.2

1.5

Switching time

TSW

f=0.05~2.5GHz
