NJG1507R

- 1 -

SPDT SWITCH GaAs MMIC

nGENERAL DESCRIPTION

nPACKAGE OUTLINE

NJG1507R is a GaAs SPDT switch IC which exhibits low

loss and high isolation, and ideally suitable for T/R switch of

the digital wireless phone.

This switch is operated in the wide frequency range from

50MHz to 3.0GHz at low operating voltage from +2.5V with

small VSP8 package.

nFEATURES

lSingle and low positive supply voltage

+2.5~+5.5V

lLow insertion loss

lTransmission power

lHigh isolation

lLow control current

lPackage

VSP8 (Mount Size: 4.0x2.9x1.2mm)

nPIN CONFIGURATION

nTRUTH TABLE

H

L

L

H

L

H

L

H

P1-PC

OFF

ON

Loss =15dB

Loss =16dB

P2-PC

ON

OFF

Loss =15dB

Loss =16dB

NJG1507R

R TYPE

(Top View)

6

7

8

1

2

3

4

5

Pin Connection

2.P2

3.GND

4.GND

5.PC

6.GND

7.P1

Note) The values of "Loss” and “Return Loss” are typical values at 2.0GHz.
