background image
SANGDEST
MICROELECTRONICS
Technical Data
Green Products
Data Sheet N1659 Rev. -
• Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
• FAX (86) 25-87123900 • World Wide Web Site - http://www.sangdest.com.cn • E-Mail Address - sales@ sangdest.com.cn •
MBR0520WS
Maximum Ratings and Electrical Characteristics
Maximum Ratings:
Characteristics
Symbol
Condition
Max.
Units
Repetitive Peak Reverse
Voltage
VRRM
-
20
V
Average Forward Current
IF (AV)
50% duty cycle @ TA=55°C,
rectangular wave form
0.5
A
Peak One Cycle Non-
Repetitive Surge Current
(Per leg)
IFSM
8.3ms, Half Sine pulse
10
A
Electrical Characteristics:
Characteristics
Symbol
Condition
Max.
Units
Forward Voltage Drop*
VF
@ 0.5A, Pulse, TJ = 25°C
0.45
V
Reverse Current*
IR1
@VR = rated VR
TJ = 25°C
100
μA
Junction Capacitance
CJ
@V
B
R
B
= 5V, T
B
C
B
= 25
°C
f
B
SIG
B
= 1MHz
75
pF
* Pulse width < 300 µs, duty cycle < 2%
Thermal-Mechanical Specifications:
Characteristics
Symbol
Condition
Specification
Units
Junction Temperature
TJ
-
-55 to +125
°C
Storage Temperature
Tstg
-
-55 to +150
°C
Maximum Thermal
Resistance Junction to
Ambient
RθJA
DC operation
120
°C/W
Case Style
SOD-323
