MBR0520WS

MBR0520WS SCHOTTKY BARRIER RECTIFIER DIODE

Features:

•

Lead-less chip form

•

Low Vf

•

High current capability

•

Low power loss/high efficiency

•

UL 94V-0 class package material

•

This is a Pb − Free Device

•

All SMC parts are traceable to the wafer lot

•

Additional testing can be offered upon request

Mechanical Data:

•

Case: SOD-323, Molded Plastic

•

Terminals: Plated Leads Solderable per MIL-STD-202, Method 208

•

Polarity: Cathode Band

•

Weight: 0.004 grams(approx)

Mechanical Dimensions: In mm / Inches

SOD-323(CJ)
