AD8233
Data Sheet
Rev. 0 | Page 12 of 29
5µV/DIV
200ms/DIV
Figure 27. 0.5 Hz to 40 Hz Noise
100
–100
03.5
INPUT COMMON-MODE VOLTAGE (V)
–80
–60
–40
–20
0
20
40
60
80
0.5
1.0
1.5
2.0
2.5
3.0
Figure 28. Input Bias Current vs. Input Common-Mode Voltage
1.5
1.0
0.5
0
–0.5
–1.0
–1.5
100
1M
100k
10k
1k
LOAD (Ω)
–40°C
+25°C
+85°C
Figure 29. Output Voltage Swing vs. Load
120
0
10
20
0.1
1
10
100k
10k
1k
100
FREQUENCY (Hz)
30
40
50
60
70
80
90
100
110
Figure 30. Power Supply Rejection Ratio
