background image
AD8233
Data Sheet
Rev. 0 | Page 16 of 29
SYSTEM PERFORMANCE CHARACTERISTICS
80
0
–40
100
TEMPERATURE (°C)
–20
20
040
60
80
10
20
30
40
50
60
70
+VS = 1.8V
+VS = 3V
+VS = 3.5V
SDN = HIGH, AC/DC = LOW, RLD SDN = LOW
Figure 44. Supply Current vs. Temperature
900
0
–40
100
TEMPERATURE (°C)
–20
20
040
60
80
100
200
300
400
500
600
700
800
SDN = LOW, AC/DC = LOW
RLD SDN = LOW, LOD = HIGH
+VS = 1.8V
+VS = 3V
+VS = 3.5V
Figure 45. Shutdown Current vs. Temperature
900
0
–40
100
TEMPERATURE (°C)
–20
20
040
60
80
100
200
300
400
500
600
700
800
SDN = LOW, AC/DC = LOW
RLD SDN = LOW, LOD = LOW
+VS = 1.8V
+VS = 3V
+VS = 3.5V
1000
Figure 46. Wakeup Current vs. Temperature
10k
1k
100
10
0.1
1
10
100k
10k
1k
100
FREQUENCY (Hz)
Figure 47. Voltage Noise Spectral Density (RTI) (Measured at IAOUT)
5µV/DIV
200ms/DIV
Figure 48. 0.5 Hz to 40 Hz Noise (RTI) (Measured at IAOUT)
10µV/DIV
2s/DIV
Figure 49. 0.05 Hz to 150 Hz Noise (RTI) (Measured at IAOUT)
